구분 / 기종 Item / Model |
단위 Unit |
HKSL-1516 | HKSL-2016 | HKSL-3016 | HKSL-2032 | HKSL-3032 | HKSL-4032 |
---|---|---|---|---|---|---|---|
재료폭 Material Width |
㎜ | 150 | 200 | 300 | 200 | 300 | 400 |
재료두께 Material Thickness |
㎜ | 0.6~1.6 | 0.8~3.2 | ||||
이송속도 Top Speed |
㎜ | 16 | |||||
코일중량 Coil Weight |
㎏ | 1,000~2,000 | Max. 2,000 | ||||
코일내경 Material Dia |
㎜ | 400(508) | 508 | ||||
코일외경 Material Out Dia |
㎜ | 1,000 | 1,200 | 1,500 | |||
핀치압착 Pinch Roll Up/Down |
- | 캠 핸들 Cam Handle |
에어 실린더 Air Cylinder |
||||
사용전원 Power Supply |
V | AC 220V (380) | |||||
운전방식 Operating Mode |
- | Dancing Bar | |||||
옵션 Options |
- | 인버터(Inverter), 행거덮판(Hanger Cover) 유압확축식(Possible to Enlarge or Reduce Through Hydraulic Pressure) |
