구분 / 기종 Item / Model |
단위 Unit |
HKU-100 | HKU-300 | HKU-500 | HKU-130 | HKU-230 | HKU-240 |
---|---|---|---|---|---|---|---|
재료폭 Material Width |
㎜ | 150 | 200 | 300 | 300 | 300 | 400 |
코일중량 Coil Weight |
㎏ | 100 | 300 | 500 | 1,000 | 2,000 | |
코일내경 Material Dia |
㎜ | 200~400 | 300~500 | 400~500 | 508 | ||
코일외경 Material Out Dia |
㎜ | 800 | 1,000 | 1,200 | |||
드럼확축방식 Drum Expansion |
베벨기어식 | 수동핸들식 (Manual Operation) | 감속핸들식 (Reduction Operation) | ||||
모터용량 Main Motor |
㎾ | 0.2 | 0.4 | 0.75 | 1.5 | 2.2 | |
사용전원 Power Supply |
V | AC 220V (380) | |||||
운전방식 Operating Mode |
Dancing Bar, Photo Sensor | ||||||
옵션 Options |
인버터(Inverter), 행거덮판(Hanger Cover), Double Uncoiler |
구분 / 기종 Item / Model |
단위 Unit |
HKU-350 | HKU-360 | HKU-540 | HKU-560 | HKU-580 |
---|---|---|---|---|---|---|
재료폭 Material Width |
㎜ | 500 | 600 | 400 | 600 | 800 |
코일중량 Coil Weight |
㎏ | 3,000 | 5,000 | |||
코일내경 Material Dia |
㎜ | 508 | ||||
코일외경 Material Out Dia |
㎜ | 1,200 ~ 1,400 | ||||
드럼확축방식 Drum Expansion |
유압확축식 (Possible to Enlarge or Reduce Through Hydraulic Pressure) | |||||
모터용량 Main Motor |
㎾ | 2.2 | 3.75 | |||
사용전원 Power Supply |
V | AC 220V (380) | ||||
운전방식 Operating Mode |
Dancing Bar, Photo Sensor | |||||
옵션 Options |
인버터(Inverter), 행거덮판(Hanger Cover), Double Uncoiler 유압 확축식(Possible to enlarge or reduce through hydraulic pressure) |
